Construction Machinery |

Features:
-Perkins water-cooled diesel engine.
-Imported hydraulic variable plunger pump.
-Imported plunger motors for double drum hydraulic drive.
-Hydraulic motor drives drum vibration; switch freely between single and double drum modes.
-Hydraulic steering.
-Dual control handles with vibration button.
-Extra-large plastic water tank, corrosion-free and easy to use for water spraying.
-Wear-resistant, liftable scraper.
-Front and rear working lamps
| Model | GRS1200P403D |
| Vibration frequency Hz | 60 |
| Centrifugal force kN | 2x30 |
| Traveling speed km/H | 0-12 |
| Gradeability % | 30-40 |
| Static line force N/cm | 125/115 |
| Drive system | Hydraulic Transmission |
| Vibration system | Hydraulic Vibration |
| Water tank capacity L | 200 |
| Hydraulic system oil capacity L | 48 |
| Emergency braking/stop |
Emergency Button
Botão de parada de emergência
|
| Steel wheel size(L x Dia) mm | 1200x Φ700 |
| Shipping dimensions mm | 2800×1515×2050 |
| Operating weight kgs | 2900 |
| Engine manufacturer | Perkins |
| Engine model | Perkins 403D-15 |
| Max.output hp | 32.7 |
