Features
1.The pendulum vibrators can efficiently compact up to 25m3/h of concrete.
2.LUDWIG pendulum system yields 12000 v.p.m from a shaft rotation frequency of just 3000 v.p.m.
3.The final result is an optimal compaction of the concrete and a reduction in the effort required and production costs.
4.Its equally efficient operation with an electric engine, or petrol or diesel engine means it can beadaoted
to all kinds ofbuilding conditions.

5.Different types of couplings.

Model	GVP/GVS32	GVP/GVS38	GVP/GVS45	GVP/GVS50	GVP/GVS60	GVP/GVS70
vibrator head Dia*Length mm	32×442	38×442	45×442	50×442	60×442	70×442
Vibrator amplitude mm	1	1.2	1.25	1.3	1.35	1.4
Frequency Hz	225	225	225	225	226	200
Revolution of flexible shaft rpm	3000-3600	3000-3600	3000-3600	3000-3600	3000-3600	3000-3600
Flexible hose length m	Standard 6m or customized
Approx weight kg	11	12	13	16	17	18
Coupling (Optional)	DYNAPAC TYPE, JAPANESE TYPE, CHINESES TYPE
